Form Factor Mini PC
Dimension 126mm*126mm*42mm
Weight(g) TBD
Material All Plastic House
VESA Support
Platform Intel® Celeron® Processor N Series
CPU Intel® Jasper Lake N5105
Process N5105 /4 Cores/4 Threads
TDP 10W
Intel® UHD Graphics
Supports 4 MB L3 Cache
Memory So-DIMM*2 4G/8GB/16GB
Storage eMMC(Option) 32G/64G/128G
SSD(Option) 128G/256G/512G; 22mm*80mm, sata 3.0 or pcie*4
HDD(Option) 2.5inch 500GB/1T/2T when need HDD,SSD must use PCIE*4
WIFI/Bluetooth M.2 2230 AC WIFI / 9461 / 9462I/O USB 3.1(Type A) x2, Type A
USB 2.0(Type A) x2, Type A
HDMI*1, standard, hdmi out
LAN(RJ45)*1 10M/100M/1000M
Type-c x1, data only 2.0 / DP+USB3.0 (Option)
DC IN*1,₵5.0mm
DP x1, DP out *1
Audio Audio out & Mic x1 ES8326 CTIA
Hot Keys Power Button *1
Reset Button *1
Power AC adapter 100~240V, 50/60Hz, 12V/3A
Battery RTC 2032
Sofrware Support OS Windows 11 pro/Linux
